Product Details
Specifications
| FIBER METERIAL | SILICA GLASS |
| CLADDING DIAMETER | 125 UM |
| CLEAVED LENGTH | SINGLE FIBER:8~20MM/RIBBON FIBER:10MM |
| APPLICABLE FIBER CABLE | SINGLE FIBER:250UM,900UM,3.0MM; FIBER CABLE AND FLAT CABLE RIBBON FIBER:2 TO 12 RIBBON FIBER CABLE |
| TYPICAL CLEAVED ANGLE | LESS THAN 0.5 ° |
| TYPICAL BLADE LIFE | TOTAL 48,000 FIBER CLEAVES(REPLACEABLE) |
| OFF-CUT COLLECTOR | PRE-FITTED |
| TYPE OF OFFCUT BIN | MANUAL |
| AUTO RETURN | PRE-FITTED |
| FIBER HOLDER | DOUBLE FIBER HOLDERS |
| FORM FACTOR | 85(W)×89(D)×45(H)MM |
| WEIGHT | 208G |
